The Image control inserts an image in the design. The image that is selected for insertion can be an image file referenced by a URL, or it can be a string that is Base64-encoded image data. The Image Source Type property specifies which of the two types the image is: a URL-located file, or a Base64 string. To specify that the image (URL or Base64 string) is taken from a page source node, drop that node onto the image control. The Image control's properties are listed below.


Note:   If the image source (URL or Base64 string) is changed during simulation or while the solution runs, then the image must be explicitly reloaded with the Reload action. For example, if a combo box selection changes the selection of an image, a Reload action targeting the image must be defined on the combo box.



Image events

The OnImageClicked event is available. To define actions for the image's OnImageClicked event, right-click the image and, from the context menu that appears, select Control Actions for OnImageClicked. This displays the Actions dialog for image events. For a description of the actions that can be defined for this event, see the Actions section.



Image properties

The control's properties are available in the Styles & Properties Pane, and are listed below in the order in which they appear.
